Liebert nx 20KVA 3 phase ups 38SA020C0CHJ power unit

* Attributes Double conversion online
* Battery Run Time (max) 16 minute(s)
* Actual Weight 550.00 lb(s)
* Physical Dimensions 63"h x 24"w x 32.5"d
* Power Notes Rated power: 20kVA
* Rated AC input voltage: 380 / 400 / 415VAC
* Input voltage tolerance: 305 to 477V
* Frequency: 50 / 60Hz (tolerance 40 to 70Hz)
* Power factor: 0.99 kW/kVA at full load, 0.98 kW/kVA at half load
* Input power: 17.8kVA at rated, 23.3kVA maximum
* Input current: 25.8A at rated, 33.8A maximum
* Harmonic current distortion: 3% THDI FL
* Duration of progressive power walk-in: 10 seconds to reach full rated current (selectable 5 through 30 seconds in 5-second intervals)
