Nib veterinary hand-held patient monitor ecg+ p+SPO2+pr

Routine Check Mode and Continuous Monitoring Mode
Data Graph and Trend Table Review
Convenient operation by touch screen
Large SD card memory for more than 2000 patient cases storage
Sync with PC based Software (WinXP and WinVista)
Display Mode: Standard face, Waveform face, SPO2 view, ECG view, BigNum view
Indicator: Power indicator light, Alarm sound, Pulse tone
Interface: One dual-purpose socket for connecting sensors and communication cables
Battery: Built-in Li-Polymer, 2 hours for charging, 3 hours for continuous working.10 hours for standby mode
Trend Graph: Resolution from 1s, 5s, 10s., maximum time 96 hours.
Trend Table: Resolution from 1s, 5s, 10s. Review up to 1000 items.
Alarm: Adjustable High and Low limits. Three level audible and visual alarm
User Configuration: All the color of parameters and waves can be set according to user's willing
Meet the requirement of IEC60601 series
Type of Protection: Class II with internal electric power supply
Dimension and Weight: 92(W)x82(H)x22(D)mm, 136g(with battery)
Operation Environment: Temperature: 0 ~ +40 . Humidity: 15% ~ 95%
Storage Environment: Temperature: -20 ~ +60 , Humidity: 10% ~ 95%
Patient Range: Neonate, Pediatric and Adult
Suitable for pet and animals (such as dog,cat,....)
Accuracy: 2%(70%~100%, Adult/Pediatric, non-motion)
3%(70%~100%, Neonate, non-motion)
Measurement Range: 25 ~ 250 bpm
Accuracy: bpm (non-motion)
Lead selection: I, II, III, AVR, AVL, AVF, V
Accuracy: 2bpm or 2%, which is greater
S-T segment detection, range: -2.0mv ~ +2.0mv
Arrhythmia analysis: 13 kinds of arrhythmia
Mode: Manual/Auto/Continuous
Measurement Range: 25 ~ 260mmHg
Auto Measure Interval: 5, 10, 15, 30, 45, 60, 90 minutes
Overpressure Protection: 300mmHg
