Tyco QRW040A0M1 40A 48VDC - 1.5VDC dc-dc converter

Tyco QRW040A0M1 40A 48VDC - 1.5VDC DC-DC Converter
The QRW-series dc-dc converters are a new generation of DC/DC power modules designed for optimum efficiency and power density. The QRW provides up to 40A output current in an industry standard quarter brick, which makes it an ideal choice for small space, high current and low voltage applications. The converter uses synchronous rectification technology and innovative packaging techniques to achieve ultra high efficiency. Thanks to the ultra high efficiency of this converter, the power dissipation is such that for most applications a heat sink is not required.
40A, 1.5VDC output 48VDC input Tightly regulated output, typical 1% Monotonic start-up into pre-biased output Output voltage adjustment trim +10% / -20% Load regulation 0.2% Line regulation 0.2% No minimum load required Operating temperature range: -40 C to 110 C 1500Vdc isolation voltage Remote output voltage sensing
